ADVANTAGES of the DIE THERMAL CONTROL SYSTEM

Benefits

  • Controlled start-up ramps for die life extension
  • Preset start-up cycles for scrap reduction
  • Faster sampling of new dies, tools and castings
  • Optimized spray and lubrication cycle
  • Customized spray cycle depending on the release agent in use
  • Local and punctual measurement of temperature without thermocouples
  • View of thermal images in real time during process
  • Live view of temperature distribution of the fix and mobile die
  • Control and monitoring of the HPDC manufacturing process
  • ID map of the die
  • ID map of the casting
  • Series thermographic records during manufacturing
  • No stops of the HPDC cells

Indirect benefits coming from the use of DTC

  • Improved surface thermal temperature distribution, with lower die thermal shock
  • Waste water reduction thanks to an optimized spray cycle
  • Correlation of casting parameters, i.e. casting defect and local die temperature
  • Improvement of casting quality (cold flows, shrinkages, porosities, die soldering…)
  • Improvement of productivity
  • Improvement of the OEE (Overall Equipment Effectiveness) of the HPDC cell
  • Possible management of thermoregulation and cooling system
  • Possible interface with the spray equipment
